Aspire CF SUB OHM Carbon Fibre Mod
Aspire cf MOD battery supply intense power for low resistance atomizer. Compatible with: 18650 battery (battery not included) Charging: An external third party charger is required. Remove the 18650 battery from the CF MOD battery holder and place it into the external charger. The CF MOD battery holder is not compatible with Aspire USB charger. -
CF Battery Technical Specification (For MOD) Status procedure Description Using Turn ON/OFF Press button 5 times in succession in 2 seconds. The LED will blink 3 times
(both blue and orange lights) and the button will illuminate Blue when active
and ON. Repeat this procedure to turn battery OFF. Usage Press the LED button and inhale at the same time LED Light Indicator Blue LED light will display for battery cell voltage of 3.5-4.2V.
The Orange LED indicates a voltage less than 3.5V. Output Voltage 4.2V full power output Compatible with 18650 battery Features Protective electronic switch PROTECTION
FUNCTIONS Overdischarge Protection When battery cell voltage is less than 2.8V (low battery), the atomizer will remain OFF,
and the Orange LED light will blink 15 times. Atomizer Short Circuit Protection If heating coils are short-circuited while vaping, the LED lights (both colors) blink 3 times,
and the battery will default to “sleep mode.” Lock and Unlock Function To lock the battery, press the button 5 times in succession in 2 seconds.
The LED lights (both colors) will flash 3 times. Repeat this procedure or
recharge to unlock. Caution Battery Care Do not store battery in a hot or humid environment.
Do not drop or puncture battery.
Do not force battery connection to other attachments. Warning Always keep the battery dry and away from moisture.
Do not dismantle or expose the battery compartment- this will result in malfunction.
If the indicator light displays ON continuously or the product becomes hot - immediately disconnect the battery from the cartridge to break the electrical connection. -
